Steel Truss Rail Bridges

Engineered steel truss bridges designed for strength, longevity, and visual impact.
Built for golf courses, resorts, municipalities, and private properties, our bridges deliver dependable performance while complementing the landscape.

  • Vehicle and pedestrian-rated designs
  • Proven steel truss construction
  • Low-maintenance, long-term durability
Don’t just take our word for it—hear from one of our customers.
Start Your Bridge Project

Key Features

Designed for fast, no-hassle installation with minimal equipment.

  • Delivered as fully assembled steel spans

  • No complex on-site construction or specialized crews required

  • Straightforward installation using basic equipment

  • Ideal for remote or hard-to-access locations

Built with durable, low-maintenance steel, these bridges provide a permanent access solution with minimal upkeep. Perfect for spanning creeks, drainage channels, and uneven terrain—without disrupting the surrounding land.

Structural Specifications

  • Load Rating
    • Designed for an 8-ton live load capacity, suitable for golf carts, light vehicles, and continuous pedestrian traffic.
  • Structural System
    • Welded steel truss design engineered to provide high strength-to-weight efficiency, lateral stability, and long-term structural reliability.
  • Decking System
    • 3″ × 12″ pressure-treated Douglas Fir timbers, specified for exterior bridge applications and rated for an estimated 50-year service life under normal use conditions.
  • Protective Coating
    • Black powder-coated steel finish for corrosion resistance and environmental protection.
  • Application Scope
    • Suitable for permanent installations across creeks, drainage channels, and uneven terrain in golf, resort, agricultural, municipal, and private property environments.

Find the bridge that you NEED

8′ wide

Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 20′ (24″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 4,820 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 20′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 4,820 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 24′ (24″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 5,784 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 24′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 5,784 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 30′ (24″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 7,230 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 30′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 7,230 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 40′ (24″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 9,640 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 40′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 9,640 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
bridge with 42" truss rail

8′ x 48′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 11,568 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 56′ (50″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 14,112 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 64′ (50″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 16,128 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

8′ x 72′ (54″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 18,144 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote

10′ wide

Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 20′ (24″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 5,740 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 20′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 5,740 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 24′ (24″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 6,888 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 24′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 6,888 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 30′ (24″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 8,610 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 30′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 8,610 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 40′ (30″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 11,480 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 40′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 11,480 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 48′ (42″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 13,776 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 56′ (50″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 16,632 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 64′ (56″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 19,008 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote
Modular pedestrian bridge with Warren truss, timber deck and black finish.

10′ x 72′ (63″ Truss Rail)

  • 8-Ton Load Capacity (16,000 lb.)
  • Bridge weight 21,384 lbs
  • Copper Naphthenate Long-life Protection
Request a Quote

Project Gallery

Warren truss bridge with timber deck used for horseback riding over a creek.
Pedestrian bridge with galvanized deck in wooded area for utility access.
Utility bridge with galvanized finish and plate deck for equipment crossing.
Pratt truss bridge supports tractor; painted with wooden deck; over creek.
